01
16× PoE+Gigabit Ports
L3 RoutingOSPF / RIP
4× 10GSFP+ Uplinks
280WPoE Budget
01 · The Power
16-Port
PoE+ Power
One cable does both jobs. Each of the 16 Gigabit ports delivers up to 30W of PoE+ power alongside data — eliminating separate power supplies for every access point, IP camera, VoIP phone, and IoT device. A 280W total budget runs a full deployment of PoE devices simultaneously, without a single power brick in sight.
280WTotal PoE Budget · 16 Gigabit Ports · IEEE 802.3at
One Cable, Two Jobs
Power and data over a single Cat5e/Cat6 run — ideal for access points, cameras, and phones in spaces where separate power is impractical.
02 · The Intelligence
Layer 3
Intelligence
Most small switches stop at Layer 2 — they separate VLANs but can't route between them. The ASW210 does both at wire speed. Static routing, RIP, and OSPF mean inter-VLAN traffic — guest WiFi to staff WiFi to security cameras — is routed locally inside the switch, without sending every packet to an overloaded firewall upstream.
Inter-VLAN Routing — On the Switch
VLAN 10 · Guest
VLAN 20 · Staff
VLAN 30 · Cameras
ASW210L3 Routed
Traffic between VLANs is routed on the switch at wire speed — not backhauled to the gateway — cutting latency and offloading the firewall.
03 · The Uplink
4× 10G SFP+
Uplinks
16 devices generating Gigabit traffic need a fast path to the core. Four 10G SFP+ uplinks give the ASW210 40 Gbps of total uplink capacity — enough to aggregate all 16 access ports without any bottleneck. Connect via fiber for long runs to the distribution switch, or use DAC cables for low-cost, short rack connections.
10GSFP+ 1
10GSFP+ 2
10GSFP+ 3
10GSFP+ 4
40GAggregate
No Uplink Bottleneck
A 1G uplink saturates fast when 16 devices are active. Pair the ASW210 with the EZE-CSW510 core over 10G for a fully managed backbone.
04 · In Control
Enterprise
Management
A full L2/L3 feature set — 802.1Q VLANs, QoS prioritisation, port-based ACLs, storm control, IGMP snooping, and LLDP discovery. Manage through web GUI, CLI, or SNMP. EZELINK ships every ASW210 pre-configured via Zero Touch Provisioning, with ongoing management from our GCC NOC so your team focuses on the business, not the network.
VLAN802.1Q tagged VLANs, inter-VLAN routing
QoS802.1p, DSCP, port-based priority
SecurityACL, storm control, DHCP snooping
AccessWeb GUI, CLI, SNMP v1/v2/v3
DiscoveryLLDP neighbour discovery
ProvisioningZero Touch Provisioning · 24/7 NOC
